MEWSQ-Z-III(5000A) Three-phase temperature rise high current system Send email to us

● Large-screen LCD display of data such as current, time, status information and prompt information, with clear and intuitive readings; connect to a computer to operate and control the device;

● Full English interface, simple and clear operation, suitable for a variety of applications;

● All touch screen buttons can be operated, intuitive, fast and easy to use.

● Fully digital calibration method, abandons the old potentiometer adjustment, extremely convenient for on-site use, and easy to control accuracy;

● Status reminder function, guided operation, even without instructions, you can operate proficiently;

● Pause function: When the test is automatically controlled, this function can pause the current rise/fall process at any point. The pause time can be flexibly controlled by the test personnel, which is convenient for observing the test product status;

● Automatic timing function: when the test is paused, the timing stops and the pause time starts. When the test is continued, the output time starts again.

● Manual timing function: when the test is manually controlled, the timer can be started manually.

● Manual control mode, this mode is similar to the traditional electric raising/lowering mode. The increase/decrease of current is controlled by buttons. The equipment automatically determines the upper/lower limit and has overcurrent protection and other functions. The entire test process is manually controlled and operated on demand;

● Status reminder function. If the temperature rise does not exceed 1ºC within one hour, a dialog box will pop up to prompt that the test can be ended;

● With stop/emergency button, it can be manually restored;

● Intelligent control of current rise and fall speed. When the current approaches the target current, the rising speed will automatically slow down;

● Data export function. The device data can be stored on the computer through a U disk for further processing.

● When overcurrent and other faults occur, the protection is immediate, accurate and reliable;

● The combination of hardware and software anti-interference technology has stable performance and strong anti-interference ability. There will be no abnormal phenomena such as freezing, black screen and flower screen during the test.

Rated capacity (common parameters): 60kVA*3
Input current: AC 0 ~ 157.8A
Output voltage: AC 0 ~ 12V
Output current: AC 0 ~ 5000A*3
Voltage measurement accuracy: 0.5% FS ± 3 digits
Current measurement accuracy: 0.5% FS ± 3 digits
Timing length: 0 ~ 999S
Power supply voltage: AC 380V ± 10%, 50Hz ± 1 Hz
Ambient temperature: -10--40℃
Altitude: <1000M
Relative humidity: <85%
There should be no gas, steam, chemical dust and other explosive and corrosive media that seriously affect insulation in the use site
