MOEORW-5060A Switchgear Partial Discharge Detector Send email to us

1. Suitable for live partial discharge detection of power equipment such as ring network cabinets and switch cabinets at different voltage levels.
2. It can provide a variety of analysis methods such as partial discharge amplitude spectrum, period spectrum, phase spectrum, waveform spectrum, PRPS/PRPD spectrum, etc., to effectively determine the amplitude, type and severity of partial discharge.
3. Real-time monitoring, can visually observe the changes in partial discharge signals.
4. It has a variety of phase synchronization methods, including internal synchronization, wireless synchronization, etc., to keep the instrument phase consistent with the on-site power frequency phase.
5. It supports intelligent power frequency synchronization function. When the instrument detects partial discharge signals, it can automatically determine the power frequency of the power grid through artificial intelligence technology to ensure that the detection spectrum is synchronized with the power grid frequency.
6. Equipped with data management and analysis software, it can uniformly analyze and manage the detection data.
7. The data analysis software has the spectrum library management function, which can classify and organize the case spectrum library.
8. It has the function of indicating the severity of discharge in yellow, green and red colors.
9. Data saving function: partial discharge detection data can be synchronously stored in the detector together with equipment information.

Host parameters
Host: Handheld design, the shell is made of ABS + fiberglass, and the double sides are covered with rubber to improve the drop resistance.
Display: 4.3-inch 480 x 800 high-definition screen.
Touch screen: Capacitive screen
Host system: The host uses the Linux system, has the function of connecting to the network, and supports 4G and WiFi Internet access.
Memory capacity: 8G
Host size: 181x107x36mm
Host weight: 0.45kg
Power supply: Built-in rechargeable lithium battery, automatically shut down when the battery voltage is low or there is no operation for a long time.
Charging method: Type-C port 5V/2A charging.
Charging time: 5 hours
Standby time: 12 hours
Working environment: Temperature: -5~55℃; Humidity: 0~90%
